Component catalogue

Bracket for attachment of 4 cables on BP mast

Variants

Catalog number Component name L [mm] Range of Use [mm] Weight [kg]
A34/IV/A Bracket for attachment of 3 cables on BP mast 500 350-410 4.695
A34/IV/B Bracket for attachment of 3 cables on BP mast 600 411-510 5.072
A34/IV/C Bracket for attachment of 3 cables on BP mast 700 511-610 5.449
A34/IV/D Bracket for attachment of 3 cables on BP mast 800 611-710 5.826
A34/IV/E Bracket for attachment of 3 cables on BP mast 900 711-810 6.203
A34/IV/F Bracket for attachment of 3 cables on BP mast 1000 811-910 6.580
A34/IV/G Bracket for attachment of 3 cables on BP mast 1100 911-1010 6.957
A34/IV/H Bracket for attachment of 3 cables on BP mast 1200 1011-1110 7.334
A34/IV/I Bracket for attachment of 3 cables on BP mast 1300 1111-1210 7.711
A34/IV/J Bracket for attachment of 3 cables on BP mast 1400 1211-1310 8.088
